Fully Automatic Sugar Stick Packing Machine
This is a vertical form-fill-seal (VFFS) packaging machine that utilizes a rotary volumetric cup dosing system, distinguishing it from models equipped with multi-head weighers. Designed as a compact, all-in-one unit, it eliminates the need for external equipment such as multi-head weighers or bucket elevators; the machine independently handles the entire process—bag forming, dosing, filling, sealing, and cutting—making it an ideal, cost-effective solution for small-to-medium-scale granular packaging operations.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Complete Operating Cycle
Material is poured into the top hopper;
The motor drives the rotary plate, filling the measuring cups with material, while a scraper levels off the excess;
The measuring cup rotates to the discharge station, and the material drops into the pre-formed film tube;
The film is pulled downward; the vertical seal closes the side, and the horizontal seal closes the bottom;
After filling, the horizontal seal closes the top, the cutter severs the bag, the finished product drops, and the cycle repeats.
Performance Parameters and Accuracy
Metering Principle: Volumetric cup filling
Packaging Speed: 20–45 bags/min
Weight Range: 5–200g
Accuracy: ±10g to ±25g (influenced by material specific gravity and particle uniformity). Higher uniformity yields better accuracy; high oil content or significant particle size variation increases the margin of error.
