Automatic Small Sachet Packing Machine
1.Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.
2.Computer PLC control and automatic alarming function.
3. English and Chinese human-machine operation interface, it is easy to operate, a high degree of automation.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Products Description
Automatic small sachet packing machine introduction
1. Computer control
Microcomputer panel control, clear and clear LCD display, easy and fast operation
2. Integrated design
The automatic small sachet packing machine automatically tracks the color code and completes the process of measuring, filling, sealing, printing date, cutting, conveying, etc.
3. High accuracy
Automatic small sachet packing machine is metered by pneumatic piston pump. The pump body is made of stainless steel, which is accurate in positioning and convenient in adjusting the volume.
4. Easy to adjust
Horizontal horizontal mixing, with the amount of packaging of the suction device can be adjusted in the range of the limit.
5. Automatic center of gravity film
The automatic center of gravity film pulling device can automatically tighten the waste film to ensure the heat sealing.
technical parameter
Automatic small sachet packing machine technical parameter
Products structure
Working Principle
Film Unwinding: Packaging roll film is guided and delivered to forming mould.
Bag Forming: Flat roll film is folded into bag shape by former.
Vertical Sealing: Vertical seal jaws heat‑seal the side of pouch.
Quantitative Filling: Rotor pump accurately injects sauce material into formed bag.
Horizontal Sealing: Top and bottom horizontal sealing finishes pouch enclosure.
Cutting & Discharge: Cutter separates finished sachets, products fall and collect.
Products effect
Applicable Materials
Tomato sauce, chili sauce, oyster sauce, salad dressing, bean paste, honey, liquid condiment and other thick liquid & particle‑containing viscous food.
Compatible Packaging Film
Heat‑sealable composite film, PE film, printed food‑grade roll film.
Suitable Industries
Condiment processing factory, instant‑food supporting factory, food OEM workshop, medium‑size food production enterprise.
