Fully Automatic Powder Packing Machine
Fully automatic powder packing machine is suitable for condiments, such as pepper, chili powder, salt, monosodium glutamate, chicken essence, milk powder, dextrose, washing powder, chemical seasoning, fine sugar, pesticides, veterinary powder, etc.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Fully automatic powder packing machine is suitable for condiments, such as pepper, chili powder, salt, monosodium glutamate, chicken essence, milk powder, dextrose, washing powder, chemical seasoning, fine sugar, pesticides, veterinary powder, etc.
No | Item | QTY |
1 | stand pouch filling sealing machine | 1 |
2 | auger feeder | 1 |
3 | powder weighing filling head | 1 |
4 | Dust removaler (powder filling) | 1 |
5 | Bag mouth Brush cleaning for good sealing effect | 1 |
1.Full-automatic weigh-form-fill-seal type, efficient and simple to use.
2.Fully automatic powder packing machine use famous brand electric and penumatic components,stable and long life circle.
Fully automatic powder packing machine
1. stand pouch filling sealing machine
model | YN-200f |
Working head | 8 |
suitable bag size | W:100-220mm L:100-380mm |
packing weight | 100-1000g |
speed | 10—35bag/min(influenced by material, and packing weight） |
machine weight | 1000Kg |
voltage | 3PH 380V 50Hz (accept customized) |
power | 3KW |
air consumption | 0.6m3 /min |
machine size | 1470(L)× 1320(W)× 1450(H)mm |
2, powder filling machine
| technical parameter hoppertransparent hopperpacking weight50- 1500gpacking error<1%speed20 - 40tine/minpower 3P 380V 50/60Hz (accept customized)power 1.4Kwweight260kgsize 1140×970×2030mm |
3, auger feeder
| main parameters Power supply: 3P 380V 50/60Hz accept customized Lifting angle: conventional 45 degrees, Lifting height: conventional 1.85 meters, Square material box with vibration device, round material box can also be customized; All stainless steel structure, material contact parts are made of 304 material; |
4,dust collector
| Working principle : The dust-containing gas is sucked into the box by the fan through the dust suction pipe, and then enters the filter bag to filter. The dust particles are retained on the surface by the filter bag. The filtered purified gas is discharged from the air outlet and can be directly discharged indoors for recycling, or as needed Exhaust outside. The dust removal efficiency is greater than 99.5%. |
Fully automatic powder packing machine can pack feel free flowing protein powder, milk powder, coffee powder, seasooning powder, spices powder, masala powder, wine powder, chilli powder, fruit powder, toner powder, medical powder so on.
