Eight structural features of pillow packaging machine

Eight structural features of pillow packaging machine

The pillow packaging machine's main body is constructed of structural components, featuring an advanced and rational design and easy installation. Its height can be adjusted according to bag size. It provides human-machine interaction for technical support throughout the entire packaging process and maintenance. Designed with environmentally friendly principles, it features a dust removal device during bag clamping to prevent dust spillage and ensure a superior working environment. It utilizes a variable-frequency speed-regulating motor with an excellent dust-proof structure and a top-brand inverter to control the feed speed, achieving stepless control.

Click on the image for more details

This is a medium-sized horizontal pillow packaging machine. Its operating principle is that the film roll is fed into the former via a driven roller and formed. The packaged material is fed into the forming machine via an infeed conveyor, where it is longitudinally sealed and transversely cut before being discharged by a discharging device.

This packaging machine is designed for solids and is suitable for packaging various solid, regularly shaped items, such as biscuits, bread, mooncakes, candy, and other foods, as well as daily necessities and industrial parts. For loose or individual items, the packaged items must first be placed in a box or bundled together to form a single unit before packaging. The same principles apply to other non-solid items.

The pillow packaging machine utilizes variable frequency speed regulation, a microcomputer controller (WDK) control system, a P1D digital intelligent temperature controller, a photoelectric detection bidirectional tracking system, a small-screen power display, and a circuit protection system. This achieves stepless speed change, automatic tracking of the cutting point, accurate temperature control, high packaging precision, intuitive display, and guaranteed safety.

Structural Features:

1) Dual inverter control allows for instant bag length setting and cutting, eliminating the need for adjustment and idle cycle time, saving time and film.

2) A text-based human-machine interface allows for quick and easy parameter setting.

3) Fault self-diagnosis function, providing clear fault display.

4) High-sensitivity photoelectric eye color mark tracking ensures more accurate sealing and cutting position.

5) Independent temperature PID control, ideal for wrapping various materials.

6) Positioning stop function, preventing knife sticking and film waste.

7) Simple transmission system, more reliable operation, and easier maintenance.

8) All controls are software-based, facilitating function adjustments and technical upgrades.
