Precautions for using pillow packaging machine

Precautions for using pillow packaging machine

Pillow packaging machines are primarily used for packaging both individual solids and multiple items. Because their control systems utilize high-quality digital control software, this not only facilitates future adjustments to the machine's functionality but also allows for timely improvements to packaging processes and methods, making pillow packaging machines more advanced. Today, we'll share some precautions for using pillow packaging machines, hoping to help you use them correctly and safely.

Click on the image for more details

1. If the temperature is too high, the speed is too slow, or the outer film has poor heat resistance, the seal will show signs of scorching. Repairs can include increasing the speed, lowering the temperature, or changing the film material.

2. If the blade holder is too high or too low, the packaging speed is too high, and the push rod and cutter are out of sync, the cutter may cut into the product. Repairs can include reducing the packaging speed and adjusting the end seal assembly so that the center of the seal is centered at the product height.

3. If the film color mark is too pale, the film drive is slipping, or color mark tracking is not enabled, the cut position may deviate from the color mark. To repair this, refer to the packaging machine manual and adjust its sensitivity; in the human-machine interface, switch the tracking mode to "Tracking Cut."

4. If the solid-state breaker is burned out, the temperature controller is damaged, or the thermocouple is damaged and the thermometer cannot control the temperature, the repair method is to replace the thermocouple, the temperature controller, or the heating element.

5. If the speed is too high, the heat sealability of the inner layer of the film is poor. If the temperature is too low, the seal may leak or become loose. To repair this, slow down the speed, increase the temperature, or replace the film material.

6. If the air pressure is incorrect, the cylinder rocker is loose, the heating temperature is low, or the heat press roller and drive roller are not parallel, the heat seal may be poor. To repair this, adjust the parallelism and adjust the temperature and air pressure to ensure a tight seal.
