Semi Auto Sauce Paste Filling Machine
The series filling machine structure is reasonable, model compact, reliable, accurate, easy to operate, Material contact parts are made of 304 stainless steel material, meet the GMP certification requirements. According to user needs within the scope of any regulation models filling volume and filling speed, high filling accuracy. Filling head adopts anti-leakage and lifting filling device.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
The series filling machine structure is reasonable, model compact, reliable, accurate, easy to operate, Material contact parts are made of 304 stainless steel material, meet the GMP certification requirements. According to user needs within the scope of any regulation models filling volume and filling speed, high filling accuracy. Filling head adopts anti-leakage and lifting filling device.
The application of machine is suitable for filling liquid sauce oil milk and such like material without granules ; also the filling machine suitable for materials with microgranules or soft granules like cream sauce etc .
Model | GW-1 | GW-2 |
Voltage | 110/220V 50/60Hz | |
Power | 300w | 500w |
Filling accuracy | 1% | |
Filling Head | 1 | 2 |
Bottle filling speed | 0-40 bottles/min | 0-80 bottles/min |
Hopper | 40L | 40L |
Equipped with air pressure | 0.6-0.8 MPa | |
Filling range | 5-50ml, 10-300ml, 50-500ml, 100-1000ml, 500-3000ml, 1000-5000ml | |
Standard export package size | 1310*380*380mm | 1310*550*380mm |
Machine Weight | 50KG | 80KG |
1. The contact part is made of SUS316 or SUS304 stainless steel materials,GMP standard; The non-metallic part with high quality materials.
2. The sealing part is made of Silicon and polyfluo, Which stands out with its anti-corrosion/temperature-resistance and anti-abrosion.
3. The Pneumatic parts for acuation is driven with compressured air without needing power supply; explosion-proof and safe in operation
4. There is two modes for machine controlling : auto and manual ; The "Manual" is controlled by pedal switch while the "Auto" in continuous filling way.
1. Good knowledge on different market can meet special requirements.
2. Real manufacturer with our own factory located in zhengzhou and wenzhou
3. Strong professional technical team ensure to produce the top quality products.
4. Rich experience on packing machinery
5. 6*12 hour service time per week.
6. do OEM and customization according different packing demand
7. all machine is 12 month warranty time
