High Speed Steam Shrink Tunnel
video
High Speed Steam Shrink Tunnel

High Speed Steam Shrink Tunnel

1. Much More Solid Stainless Steel Structure Machine
2. 2.5mm-3mm thickness wall
3. Better Design and More Groups of adjustable Steam Spreading Nozzles ,adjustable for shrinking different position of label on container

  • Fast Delievery
  • Quality Assurance
  • 7*12 Customer Service
Product Introduction



High speed steam shrink tunnel features

1. Much More Solid Stainless Steel Structure Machine

2. 2.5mm-3mm thickness wall

3. Better Design and More Groups of adjustable Steam Spreading Nozzles ,adjustable for shrinking different position of label on container

4. Equipped with water and steam separator to make steam vaporous steam ,make steam shrink application better and remaining tiny little steam on container after shrink

5. Excellent design inter layer for waist steam and Equipped with 6units of waste steam let out exit with volume valves controlable. Make sure every second the exhaust steam is gone clean by the blower fan on top .

6. Good chamber to always keep the steam shrink pressure

7. Big humanization door handle to open and close tunnel window



model

DZBS1135

steam shrink tunnel

voltage

220V 50/60HZ

power

150w

Conveyor motor

AC120w

Conveyor speed

0-10m/min

shrink tunnel

1000*100*320mm

max packing size

φ80*290mm

Capacity

5000~7500B/H

max loading

15kg

Steam Pressure

0.1Mpa

Steam Consumption

8Kg/H

Shrink Temperature

75~85℃

machine size

1760*400*1250mm

machine weight

68kg


model

ZBS83A

high speed steam shrink tunnel

voltage

220V 50/60HZ

power

150w

shrink tunnel

1350*180*380mm

max packing size

¢120 x 350H mm

Capacity

5000~15000B/H

Steam Pressure

0.1Mpa

Steam Consumption

24Kg/H

Shrink Temperature

75~85℃

machine size

2400*430*1350mm

machine weight

150kg
