Flour Milling Machine
Products Description Flour Milling Machine Stainless steel claw crusher is widely used in food, chemical, non-metallic mining and other industries, suitable for crushing dry brittle materials. The machine has simple structure, strong, stable operation, fast and uniform crushing material, and...
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Products Description
Flour Milling Machine
Stainless steel claw crusher is widely used in food, chemical, non-metallic mining and other industries, suitable for crushing dry brittle materials. The machine has simple structure, strong, stable operation, fast and uniform crushing material, and good effect. The machine is made of stainless steel material, and the interior of the shell is precision machine to achieve the effect of smooth surface and easy to clean, which changes the phenomenon of rough inner wall of the ordinary crusher, easy to accumulate powder and difficult to clean, so that the production of food, medicine, chemical industry and so on can more meet the national standards. The machine has the advantages of simple structure, convenient disassembly and assembly of crushing chamber, easy cleaning, and replacement of claw after wear. Smooth operation, low noise, low vibration. Simple operation, replacing the screen can control the size of the crushing particle size.
Products specification
Flour Milling Machine
Product Specification
|
Model |
200type |
300type |
400type |
500type |
600type |
800type |
1000type |
|
Bottom box type: length * width *height (mm) |
520*420*970 |
920*530*1235 |
1250*850*1350 |
1300*920*1390 |
1450*930*1480 |
1750*1150*1760 |
2000*1260*1950 |
|
Simple bracket type length * width*height (mm) |
450*420*970 |
870*530*1235 |
1200*850*1260 |
1400*920*1290 |
1350*930*1380 |
1550*1150*1650 |
1900*1260*1850 |
|
Spindle speed (revolutions per minute) |
7000 |
5700 |
4500 |
3900 |
3200 |
2800 |
1800 |
|
Rotor working diameter (mm) |
160 |
230 |
320 |
370 |
450 |
600 |
800 |
|
Matching power (KW) |
1.5-2.2 |
3-4 |
5.5-7.5 |
7.5-11 |
11-15 |
18.5-22 |
22-30 |
|
Weight of the bottom box type (Kg) |
85 |
120 |
196 |
270 |
315 |
550 |
750 |
|
Weight (Kg) of simple bracket type |
70 |
110 |
180 |
250 |
320 |
522 |
700 |
|
Production capacity (Kg/h) |
10-120 |
30-200 |
50-300 |
70-400 |
100-500 |
500-1500 |
800-2000 |
|
Feed particle size (mm) |
≦12 |
≦12 |
≦12 |
≦12 |
≦12 |
≦12 |
≦12 |
|
Grinding particle size (mesh) |
10-120 |
10-120 |
10-120 |
10-120 |
10-120 |
10-120 |
10-120 |
|
Select bearings |
6205 |
6207 |
6207 |
6309 |
6309 |
6312 |
6312 |
Products Details
Flour Milling Machine
Products effect
Flour Milling Machine
certificate
Products Description
Q: How is your after-sales service system?
A: We offer one-year free warranty and lifetime maintenance service after one year. After the products are shipped overseas, we provide overseas installation, commissioning and training services.
Q: May we visit your factory and inspect the machines in detail?
A: We highly appreciate the factory visit, which will offer machine testing services, face-to-face discussions, and turnkey project design solutions.
Q: If we have very special requirements for the production line, can you help me with the design?
A: We provide experienced mechanical designers for customized design.
Q: If we show you our factory layout, could you help design the entire production line for us?
A: We provide layout design services after receiving the factory layout dimensions from the customer.
