Automatic Water Bottle Filling Capping Labeling Line
This automatic water bottle filling capping labeling line is using German advanced technology, engineering and technical personnel by the company independently developed specifically for liquid filling and labeling. Filling part of the machine can be used 316L stainless steel injection pump filling, PLC control, high filling accuracy, easy to adjust the scope of the filling
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Products Description
The automatic water bottle filling capping labeling line is liquid filling line which is designed to fill bottles and jars with products ofvarious viscosity, range from water thin liquids to thick creams. Widely used in cosmetic, food, pharmaceutical, oil and specialtyindustries. These inline piston filling machines can be option with different fill heads for meet different production capacity,variable speed drive conveyor, adjustable stainless steel frame, easy to operate PLC control panel.
application
The automatic water bottle filling capping labeling line is suitable for filling all kinds of liquid and psate, such as tpmato sauce, peanut sauce, cream, alcohol, fuel, glue, gasoline, kerosene, ethanol, methanol, benzene etc.
technical parameter
|
Model |
YNGG-4(FILLING MACHINE ) |
|
Volt |
220V/50HZ(110V accept customization) |
|
Power |
200W |
|
Filling speed |
200-500bottle/hour/head |
|
Filling error |
less than ±1/% |
|
Air pressure |
0.5-0.7Mpa |
|
Gas consumption |
0.3-0.8m3/min |
|
Suitable bottle height |
90-320mm |
|
Suitable bottle dia |
≥50mm |
|
Filling nozzles |
2,4,6,8(customized) |
|
Filling range |
5-100ml 30-280ml 50-500ml 100-1000ml 500-2500ml 1000-5000ml |
|
Machine size |
2200*1000*1850mm |
|
Model |
MT-200(LABELING MACHINE ) |
|
Suitable label |
(L)25~200mm×(W)15~200mm |
|
Power |
220V 50HZ 2500W |
|
Coveyor width |
130mm |
|
Capacity |
0~180times/min |
|
Precission |
±1mm |
|
Size |
2500×1000×1800mm |
|
G.W |
300kg |
features
automatic water bottle filling capping labeling line Features
Products display
automatic water bottle filling machine
automatic capping machine
automatic labeling machine
automatic production line
packing and shipment
FAQ
Q: Are you a factory or trading company?
A: We are a factory specialized in daily cosmetic, foods, beverage, Pharmastic Filling Capping and Labeling Machine and whole production line. Such as, Liquid Filling Machine Paste Filling Machine , automatic capping machine ,semi-automatic capping machine,automatic labeling Machine and semi-automatic machine ,coding machine and other packaging mahcine.filling and other packing machines.
Q: How does your factory do regarding quality control?
A: Quality is priority. People from Youlian always attach great importance to quality controlling from the beginning to the end. We support to inspect machine before shipment Our factory has gained CE authentication
Q: What's the guarantee if we purchase from you?
A: All the equipment ordered from us will provide one year guarantee from the delivery date .If there is any main parts be broken within the warranty and isn't caused by improperly operation then we would offer the new parts for free.
Q: Would you have a discount if l have a large order?
A: Yes,we will offer a discount of varying degrees according to the quantity of the order.
