Automatic Filling Labeling Machine
This Automatic Bottle Filling Capping Machine is using German advanced technology, engineering and technical personnel by the company independently developed specifically for liquid filling and labeling. Filling part of the machine can be used 316L stainless steel injection pump filling, PLC control, high filling accuracy, easy to adjust the scope of the filling
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
This Automatic Bottle Filling Capping Machine is using German advanced technology, engineering and technical personnel by the company independently developed specifically for liquid filling and labeling. Filling part of the machine can be used 316L stainless steel injection pump filling, PLC control, high filling accuracy, easy to adjust the scope of the filling
Model | YNGG-4(FILLING MACHINE ) |
Volt | 220V/50HZ(110V accept customization) |
Power | 200W |
Filling speed | 200-500bottle/hour/head |
Filling error | less than ±1/% |
Air pressure | 0.5-0.7Mpa |
Gas consumption | 0.3-0.8m3/min |
Suitable bottle height | 90-320mm |
Suitable bottle dia | ≥50mm |
Filling nozzles | 2,4,6,8(customized) |
Filling range | 5-100ml 30-280ml 50-500ml 100-1000ml 500-2500ml 1000-5000ml |
Machine size | 2200*1000*1850mm |
Model | MT-200(LABELING MACHINE ) |
Suitable label | (L)25~200mm×(W)15~200mm |
Power | 220V 50HZ 2500W |
Coveyor width | 130mm |
Capacity | 0~180times/min |
Precission | ±1mm |
Size | 2500×1000×1800mm |
G.W | 300kg |
1.Adopt human-computer interface, PLC controller, easy to operate.
2.Use frequency converting control, easy to adjust the labeling speed.
3.Round turn table for positioning filling, stable and reliable.
automatic filling machine
automatic capping machine
automatic labeling machine
automatic production line
Q: Can a machine be used for different bottles?
A: If the size of bottle is same, you can use it. If the size is different, you need to change the chuck.
Q: How to clean the filling part of the machine?
A: Put the filling pump into the water directly, so that the machine can be filled and cleaned.
Q: Our products have some of viscosity, will it be affected when filling?
A: If it is particularly viscous, the filling pump should be replaced.
Q: If the machine is broke down. Do you provide after-sales service?
A: Our warranty period is 1 year, and engineers can go abroad to make repairs.
