Automatic Carton Sealing Packing Machine
Automatic four side sealing machine uses adhesive tape to stick on the carton parallel 4 edges and 8 corner， it is high efficiency with beautiful sealing result.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Automatic carton sealing packing machine introduction
Automatic four side sealing machine uses adhesive tape to stick on the carton parallel 4 edges and 8 corner， it is high efficiency with beautiful sealing result.
Technical characteristic
1, the automatic carton sealing packing machine adopts automatic system, equipped with photoelectric detection, with automatic, automatic alarm, etc, can realize unmanned automated operation
2, the uatomaric carton sealing packing machine is easy to transform the product specifications, easy to operate
3, the automatic carton sealing packing machine can be used directly with a production line
4, high quality international brand electrical components, quality is reliable
5, FXS5050 four side sealing machine adopts new sealing head structure, good sealing effect, stable With long lifetime
6, the whole machine is firm structure, the guide bar positioning reliable and simple maintenance
MODEL | DFXS-7050 automatic carton sealing packing machine |
VOLTAGE(V/HZ) | AC 110V/220V,50~60HZ |
POWER(W) | 720 |
GAS PRESSURE(MPa) | 0.55~0.6 |
APPLICABLE CARTON SIZE(mm) | L:260-700mm,W:200-500mm,H:180-500mm |
HEIGHT OF WROKING TABLE(mm) | 550-630mm |
TAPING SPEED（m/min） | 20 |
ADHESIVE TAPE USED | BOPP,PVC,KRAFT PAPER TAPE |
WIDTH OF ADHESIVE TAPE(mm) | 48mm，60mm，72mm |
WEIGHT OF PACKAGE（kg） | 2.5-3.0 |
EXTERNAL DIMENSION(L*W*H) | 1955*1340*1330mm |
NET WEIGHT(kg) | 400 |
 | Operation panel the automatic carton sealing packing machine operation panel is simple and beautiful, with an emergency stop switch, which can stop the running machinery immediately. |
Sealing inner, using advanced sealing inner liner, flattening the protruding part of the carton, so that the tape can be attached to the surface of the carton. |  |
 | Reasonable circuit design, wiring and layout not only meet the design requirements, but also the process is simple and beautiful. |
The automatic carton sealing packing machine is mainly used when sealing and packaging carton either individually or as part of a production line depending on the unit required.
we manufactue different kind of carton sealing machine, you can choose according to your demand.
