Steam Label Shrink Machine with Steam Generator

Steam Label Shrink Machine with Steam Generator

The steam shrink label machine is widely used in various plastic bottles with POF,PVC,PE,PP labels. It is our newly developed shrinking machine.

Product Introduction

We seize the opportunity of in-depth development and strive to advance on the road to the rise of China's Automatic Spice Packing Machine, Automatic Small Bottle Filling Machine, Automatic Small Sachet Tomato Paste Packing Machine industry. In terms of business development strategy, we actively respond to the requirements of sustainable development of the United Nations. We are in line with excellence, continuous pursuit, and active implementation of comprehensive quality management work. Our company in the long-term development, through continuous accumulation, summary, innovation and improvement, and gradually formed a unique corporate culture concept.



The steam shrink label machine is widely used in various plastic bottles with POF,PVC,PE,PP labels. It is our newly developed shrinking machine.



1.The steam shrink label machine uses steam as the heat source, fast speed, uniform heating temperature, stable and reliable.

2.The steam shrink label machine adopts waterproof design, with S/S water collector at the bottom, which can collect condensed water.

3.The steam shrink label machine adopts S/S structure, easy to operate and maintain.

4.5-section design in shrink tunnel, independent temp. Control in each section, as well as height adjust and distance adjust between objects. Any shape bottle is able to reach nice-looking shrink effect after simple adjust.



Model

ZBS83A

Voltage

220V 50-60HZ

Power

150W

Conveyor motor

AC120W/220V

Conveyor speed

0-10m/min

Max.loading

15KGS

Shrink tunnel

1350*180*380mm

Max packing size

Φ1120 x 350H mm

Capacity

5000~15000B/H

Steam Pressure

0.1Mpa

Steam Consumption

24Kg/H

Shrink temperature

75~85℃

Machine size

2400*430*1350mm

Machine weight

150KGS











Q: Why choose us?

A: 1. We are a very professional packaging machinery manufacturer.

2.We have very rich experience of the international trade business.

3.Our machine running in over 60 countries.

4.Our company has passed the third part inspect.


Q: How long is your delivery time?

A: Small quantity with in 1-7 days, big quantity within 10-30 days.


Q: What products do you mainly run?

A: Our main series includes filling machine, shrink packing machine, sealing machine, carton sealing machine, vacuum packing machine etc packing machinery and food processing machinery.


Q: Can you give me a discount?
A: There can be a discount,but it still depends on the number of machines you buy,and the discount is relatively large for the larger quantity.
