Automatic Biscuit Packing Machine

1)3 independent motors (Conveyor, center sealing and end sealing)
2)Motion controller for quick response to various commands
3)Accurate positioning
4)Digital temperature control

Fast Delievery
Quality Assurance
7*12 Customer Service

Product Introduction

Main performance and structural characteristics

1)3 independent motors (Conveyor, center sealing and end sealing)

2)Motion controller for quick response to various commands

3)Accurate positioning

4)Digital temperature control

5)Food grade SS304 contact parts

6)Touch screen

Technical parameter

Model	DK-360B	DK-360D
Film width	Max.360mm
Bag length	65-190or120-280mm	90-220or150-330mm
Bag width	50-160mm
Product height	Max.60mm
Film dia	Max.360mm
Packing speed	40-250bag/min
voltage	220V 50/60Hz 2.6kw
Machine size	(L)3770X(W)720X(H)1450mm
Machine weight	About 800kg
Note	Other demand can be customized

automatic biscuit packing machine is widely applied for various kinds of regular objects like food, medicine, daily appliances,cosmetic,metals, industrial parts, boxes, trays, toys and etc.

Q1: Can you send me the installation video of this machine?

A1: Yes, please check the link for this video

Q2: What is the material of contact food/material parts?

A2: The contact food/material parts are made of 304# stainless steel. The machine body can be 304# stainless steel or carbon steel.

Q3: Can this machine make different bag sizes?

A3: One former can make one bag width, and the bag length can be adjustable within a range. It should be ordered an extra former if you want to make the other bag width.
