Semi Auto Ketchup Filling Machine
The series filling machine structure is reasonable, model compact, reliable, accurate, easy to operate, Material contact parts are made of 304 stainless steel material, meet the GMP certification requirements. According to user needs within the scope of any regulation models filling volume and filling speed, high filling accuracy. Filling head adopts anti-leakage and lifting filling device.
- Fast Delievery
- Quality Assurance
- 7*12 Customer Service
Product Introduction
Products Description

The semi auto ketchup filling machine is paste or cream liquid filling machine, which is driven by a cylinder to extract and eject material. The material flow is controlled by a three-way rotary valve. The stroke of the cylinder can be controlled by the reed switch. The filling volume can be adjusted, You can adjust the intake air cylinder to achieve rapid or slow filling.
technical parameter
|
Model |
GW-1 semi auto ketchup filling machine |
GW-2 semi auto ketchup filling machine |
|
Voltage |
110/220V 50/60Hz |
|
|
Power |
300w |
500w |
|
Filling accuracy |
1% |
|
|
Filling Head |
1 |
2 |
|
Bottle filling speed |
0-40 bottles/min |
0-80 bottles/min |
|
Hopper |
40L |
40L |
|
Equipped with air pressure |
0.6-0.8 MPa |
|
|
Filling range |
5-50ml, 10-300ml, 50-500ml, 100-1000ml, 500-3000ml, 1000-5000ml |
|
|
Standard export package size |
1310*380*380mm |
1310*550*380mm |
|
Machine Weight |
50KG |
80KG |
Products features
1.This semi auto ketchup filling machine has two pneumatic filling ways, foot and automatic, and they can be switched randomly.
2.The part conacting materials is made of stainless steel 304 and PTFE.
3.Filling the valve head with anti-drip, antidrawing and lifting filling device.
4.There are filling volume adjustment handle,filling speed can be adjusted, filling high precision.
Products details

application
semi auto ketchup filling machine application:
Paste or cream liquid filling machine, They are suitable to fill water, beverage, oil, ink, lotion, shampoo, sauce, jam, gel,cream, etc in the field of cosmetic, drinks, chemical, medical, food, etc.

certificate

our advantages
1. Good knowledge on different market can meet special requirements.
2. Real manufacturer with our own factory located in zhengzhou and wenzhou
3. Strong professional technical team ensure to produce the top quality products.
4. Rich experience on packing machinery
5. 6*12 hour service time per week.
6. do OEM and customization according different packing demand
7. all machine is 12 month warranty time
factory corner


packing and shipment

FAQ
Q: Are you a factory or trading company?
A: We are a factory specialized in daily cosmetic, foods, beverage, Pharmastic Filling Capping and Labeling Machine and whole production line. Such as, Liquid Filling Machine Paste Filling Machine , automatic capping machine ,semi-automatic capping machine,automatic labeling Machine and semi-automatic machine ,coding machine and other packaging mahcine.filling and other packing machines.
Q: How does your factory do regarding quality control?
A: Quality is priority. People from Youlian always attach great importance to quality controlling from the beginning to the end. We support to inspect machine before shipment Our factory has gained CE authentication
Q: What's the guarantee if we purchase from you?
A: All the equipment ordered from us will provide one year guarantee from the delivery date .If there is any main parts be broken within the warranty and isn't caused by improperly operation then we would offer the new parts for free.
Q: Would you have a discount if l have a large order?
A: Yes,we will offer a discount of varying degrees according to the quantity of the order.
